5227161-6 by te connectivity / amp brand

5227161-6

TE Connectivity / AMP Brand

RTANG JK W/MTG PINS, BNC PCB ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / AMP Brand part 5227161-6 is a conveniently designed RTANG JK W/MTG PINS, BNC PCB connector. It offers a reliable and efficient solution for connecting BNC PCBs with ease. The connector features a robust construction, ensuring durability and consistent performance for various applications. With its mounting pins, installation becomes effortless, saving time and effort. This connector is a valuable component for electronic and communication systems, delivering reliable signal transmission and maintaining connection stability.

Product Highlights:

  • Connector
  • Connector Type = BNC
  • Jack
  • Terminate To Printed Circuit Board
  • PCB Mount Angle = Right Angle

Search Keywords: 52271616

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5227161-6
RoHS:
Yes
HTS:
8536694010
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
35
Package Type:
Tube
Type:
BNC
Impedance:
50 Ohm
Operating Frequency:
0 to 4 Hz to GHz
Gender:
RCP
Mounting:
Through Hole
Body Orientation:
Right Angle
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-55 to 85 °C
Dimension:
14.76 x 34.93 x 15.88 mm
  Possible Replacement options available.  See Alternatives

IN STOCK: 4,629

Ships today, if you order in

Minimum Order: 35

Multiple: 35

Factory Lead-Time 19 Weeks

Price (CAD)

Qty
Unit Price
35
$3.461
70
$3.400
280
$3.308
525
$3.262
1,015
$3.247
2,520
$3.124
5,005 +
$3.109
