5227673-1 by te connectivity / amp brand
Image is representational - see mfr. specs

5227673-1

TE Connectivity / AMP Brand

RF / Coaxial Connector - BNC Coaxial - Straight Jack - Solder - 50 ohm - Phosphor Bronze. ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 5227673-1 is a through-hole BNC Straight Jack for use with printed circuit board (PCB). It has nickel-plated zinc body with gold-plated phosphor bronze centre contact and a polymethylpentene insulator.

Product Highlights:

  • Connector
  • Connector Type = BNC
  • Jack
  • Terminate To Printed Circuit Board
  • PCB Mount Angle = Vertical

Search Keywords: 52276731

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5227673-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
35
Package Type:
Tube
Type:
BNC
Impedance:
50 Ohm
Operating Frequency:
0 to 4 Hz to GHz
Gender:
RCP
Mounting:
Through Hole
Body Orientation:
Straight
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-55 to 85 °C
Dimension:
14.76 x 15.88 x 35.57 mm
  Possible Replacement options available.  See Alternatives

IN STOCK: 4

Ships today, if you order in

You may purchase all in-stock quantity of 4

On Order: 1,645   can ship 7/22/26

Stock lot only: 4

Minimum Order Quantity: 35

Multiple: 35

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
1
$3.388
35
$3.080
70
$3.059
280
$3.018
525
$2.966
1,015
$2.833
2,520
$2.822
5,005
$2.802
7,525 +
$2.791
