535541-4 by te connectivity / amp brand
Image is representational - see mfr. specs

535541-4

TE Connectivity / AMP Brand

06 MODIV VRT SR CE 100/115 ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

535541-4 is a single-row AMPMODU receptacle assembly designed for the AMPMODU 0.025 inch square interconnection system. This 6-position receptacle features a 0.100 inch (2.54 mm) centerline spacing and is configured for vertical mounting with top entry contacts. The assembly has a recommended PCB hole layout for 0.062 inch thick PC boards, with contact dimensions of 0.600 inches (15.24 mm) overall length and 0.500 inches (12.70 mm) spacing dimension B. The receptacle includes a localized gold plate contact area measuring 0.100 ± 0.003 inches (2.54 ± 0.08 mm) and features a 0.035 ± 0.003 inch diameter contact pin. This connector is commonly used in electronic equipment requiring reliable modular interconnection with multiple plating options available for different environmental and performance requirements.

Product Highlights:

  • Receptacle
  • Mod IV
  • Number of Positions = 6
  • Number of Rows = Single
  • Low Profile

Search Keywords: 5355414

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
535541-4
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
37
Package Type:
Tube
Type:
Socket Strip
Body Orientation:
Straight
Gender:
RCP
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
6
Maximum Voltage Rating:
N/A
Maximum Current Rating:
2/Contact A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C
  Possible Replacement options available.  See Alternatives

IN STOCK: 4,987

Can Ship immediately

Minimum Order Quantity: 37

Multiple: 37

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
37
$1.599
259
$1.299
518
$1.240
1,036
$1.188
2,516
$1.138
5,032
$1.003
7,511
$0.990
10,027 +
$0.940
