5413631-1 by te connectivity / amp brand
Image is representational - see mfr. specs

5413631-1

TE Connectivity / AMP Brand

BNC Connector Jack, Female Socket 50 Ohm Through Hole, Right Angle Solder ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 5413631-1 is a through-hole BNC Right Angle Jack for use with printed circuit board (PCB). It has nickel-plated zinc body with gold-plated beryllium copper centre contact and a polymethylpentene insulator. Connector Style BNC Connector Type Jack, Female Socket Contact Termination Solder Shield Termination Solder Impedance 50 Ohm Mounting Type Through Hole, Right Angle Fastening Type Bayonet Lock Frequency - Max 4GHz Applications RF Communications, Industrial

Product Highlights:

  • Connector
  • Connector Type = BNC
  • Jack
  • Terminate To Printed Circuit Board
  • Not Stacked

Search Keywords: 54136311

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5413631-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
Pack
Type:
BNC
Impedance:
50 Ohm
Operating Frequency:
0 to 4 Hz to GHz
Gender:
RCP
Mounting:
Through Hole
Body Orientation:
Right Angle
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-55 to 85 °C
Dimension:
27.89 x 10.97 x 10.52 mm

IN STOCK: 1,489

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
5
$7.64
25
$5.93
50
$5.82
100
$5.71
250
$5.60
500
$5.56
1,000
$5.36
2,500 +
$5.33
Suppliers Standard Package
