5499206-3 by te connectivity / amp brand
Image is representational - see mfr. specs

5499206-3

TE Connectivity / AMP Brand

A/L UNIV HDR 16P VERT LG LAT ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

5499206-3 is a universal ejection style pin header with long latches designed for ribbon cable interconnect solutions. This 16-position pin header features 0.100 x 0.100 inch (2.54 x 2.54 mm) centerlines and is compatible with AMP-LATCH strain relief receptacles. The header includes 0.025 inch (0.64 mm) square posts at the mating end with a soldertail length of 0.110 inch (2.79 mm). It features contact plating finish code B (Duplex) and is RoHS compliant. This pin header is commonly used in ribbon cable assemblies for data communication, computer peripherals, and industrial control applications where reliable board-to-cable connections are required.

Product Highlights:

  • Connector Type = Universal Ejection Pin Headers
  • Standard Profile
  • Number of Positions = 16
  • 2.54 x 2.54 mm Centerline, Matrix
  • PCB Mount Angle = Vertical

Search Keywords: 54992063

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5499206-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
42
Package Type:
Tray
Type:
Ejector Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
16
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
1/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 125 °C

IN STOCK: 0

Minimum Order Quantity: 42

Multiple: 42

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
42
$2.81
84
$2.79
126
$2.74
252
$2.68
504
$2.65
1,008
$2.64
2,520
$2.62
5,040 +
$2.61
