5569380-1 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

5569380-1

STK MJ,8POS,2X1,SHLD,CAT5 ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 5569380-1 is a PCB-mounted stacked modular jack connector featuring a 2×1 port configuration with RJ45 jack type and side-entry right-angle mounting orientation. This connector is designed for Category 5 performance with 8 positions and 8 loaded contacts per port, utilizing through-hole solder termination to the PCB. The housing is constructed from PCT GF material with UL 94V-0 flammability rating, and the connector features gold-plated mating contacts over phosphor bronze base material, along with tin-over-copper shield plating for enhanced durability and signal integrity. The preloaded design with 6 PCB ground tabs and wave solder capability up to 265°C makes it suitable for high-reliability networking and telecommunications applications requiring compact stacked port configurations.

Product Highlights:

  • Jack
  • Stacked Port Configuration
  • 2 x 1 Jack Configuration
  • Jack Type = RJ45
  • Number of Positions = 8

Search Keywords: 55693801

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5569380-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8537109170
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
45
Package Type:
TRAY
Type:
RJ-45
Body Orientation:
Right Angle
Mounting:
Through Hole
Pitch:
2.54 mm
Gender:
F
Number of Contacts:
16
Maximum Voltage Rating:
150 VAC
Maximum Current Rating:
1.5/Contact A
Operating Temperature:
-40 to 80 °C

IN STOCK: 80

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 282

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
5
$14.55
50
$12.28
100
$11.88
282
$11.67
563
$11.63
844
$11.60
1,125 +
$11.57
Log in for special pricing
