55785-2

Name: 55785-2
Brand: Te Connectivity Amp Brand
SKU: 10431869
Price: 1735.5 USD
Availability: InStock

TE Connectivity / AMP Brand

SPLICE, BUTT P,G. 16-14 CLEAR ...

Datasheet

RoHS Compliant

Reel Packaging

DESCRIPTION

55785-2 is a tape-mounted PIDG butt splice designed for reliable wire-to-wire connections in 16-14 AWG applications. This pre-insulated splice features natural nylon insulation with blue stripes for easy identification and is rated for wire sizes from 2,050 to 5,180 circular mils (1.04-2.62 mm²). The splice has a maximum length of 1.065 inches (27.05 mm) and accommodates wire insulation diameters up to 0.170 inches (4.32 mm). Constructed with tin-plated copper and nylon insulation rated at 300V maximum and 105°C maximum, it meets MIL-T-7928 specifications. These splices are ideal for control circuits and power wiring applications requiring uniform, high-quality solderless terminations.

Product Highlights:

Splice
Not Sealed
Splice Type = Butt
Butt Splice Type = Standard
Body Style = PLASTI-GRIP

Potential Applications:

Search Keywords: 557852

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

55785-2

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
