5747091-2 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

5747091-2

09 RCPT ACT PIN/MS MED SCRLK ...

View Datasheet Ask the Datasheet
RoHS Compliant
Tray Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The TE Connectivity / AMP Brand part 5747091-2 is an electrical component designed for use in a variety of applications. This particular part is a 09 RCPT ACT PIN/MS MED SCRLK, which means it is a receptacle connector with active pins and a medium screw lock. It is commonly used in industrial, automotive, and telecommunications systems to provide secure and reliable electrical connections. With its compact design and sturdy construction, this part is engineered for durability and optimal performance.

Product Highlights:

  • Number of Positions = 9
  • Receptacle
  • PCB Mount Angle = Vertical
  • Product Series = HD 20
  • With Mating Connector Lock

Search Keywords: 57470912

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5747091-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
130
Package Type:
Tray
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Solder
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C

IN STOCK: 772

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 163

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
5
$35.40
50
$35.31
100
$35.23
163
$35.13
325
$18.60
488
$12.78
650 +
$12.52
Log in for special pricing
