5747150-2 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

5747150-2

D Sub Connector - DB9 - Size 1 - 9 Contacts - Receptacle - Solder - Front Metal Shell - AMPLIMITE HD-20 Series. ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 5747150-2 is a 9-way 2-row front metal-shell D-sub Receptacle with gold-plated phosphor bronze contacts and standard mounting holes. The Amplimite HD-20 series straight posted receptacle comes with black polyester housing, tin-plated carbon steel shell, brass inserts and tin-plated solder tail. All receptacles are preloaded with size 20 DF posted socket contacts. Connectors are intermateable with any size 20 subminiature D connectors dimensionally complying with MIL-C-24308.

Product Highlights:

  • Number of Positions = 9
  • Receptacle
  • PCB Mount Angle = Vertical
  • Product Series = HD 20
  • Without Mating Connector Lock

Search Keywords: 57471502

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5747150-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
17
Package Type:
TUBE
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Solder
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C

IN STOCK: 3,037

Ships today, if you order in

Minimum Order Quantity: 17

Multiple: 17

Factory Lead-Time 40 Weeks

Price (USD)

Qty
Unit Price
17
$3.88
51
$3.84
102
$3.77
255
$3.55
510
$3.50
1,003
$3.47
2,516 +
$3.38
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
