5747461-1 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

5747461-1

HD-20 RCPT 25P RA 590 ...

View Datasheet Ask the Datasheet
RoHS Compliant
Pack Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The TE Connectivity / AMP Brand part 5747461-1 is a versatile HD-20 RCPT 25P RA 590 connector that offers a reliable solution for various applications. With its right-angle design, it allows for efficient space utilization and easy cable routing. This connector is equipped with 25 pins, making it suitable for transmitting multiple signals or data. The high-quality construction ensures a secure and durable connection. Whether it is used in industrial machinery, automotive systems, or other electrical applications, the TE Connectivity / AMP Brand part 5747461-1 delivers exceptional performance and reliability.

Product Highlights:

  • Number of Positions = 25
  • Receptacle
  • PCB Mount Angle = Right Angle
  • Product Series = HD 20
  • Without Mating Connector Lock

Search Keywords: 57474611

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5747461-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
70
Package Type:
Pack
Type:
D-Subminiature
Body Orientation:
Right Angle
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Solder
Shell Size:
3
Number of Contacts:
25
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C

IN STOCK: 1,162

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
5
$6.43
25
$6.15
70
$5.96
140
$5.84
280
$5.72
560
$4.34
1,050
$3.42
2,520 +
$2.93
Supplier's Standard Package
Log in for special pricing
