5747843-4
D Sub Connector - DB37 - Size 4 - 37 Contacts - Plug - Solder - Right Angle - Front Metal Shell - AMPLIMITE HD-20 Series. ...
DESCRIPTION
The 5747843-4 is a 37-position 2-row right-angle posted PCB D-sub Connector with gold-plated phosphor bronze contacts and UL94V-0 rated thermoplastic housing. The Amplimite HD-20 series receptacle supports through-hole PCB mounting style and threaded insert, 4-40 UNC mating connector lock. This stacked PCB connector is members of the complete line of Amplimite D-sub connector family which has been accepted by the electronic industry for their rugged design and ease of application. Stacked connectors add the advantage of reducing overall board real estate normally consumed by individual PCB connectors.
Product Highlights:
- Number of Positions = 37
- Plug
- PCB Mount Angle = Right Angle
- Product Series = HD 20
- With Mating Connector Lock
Search Keywords: 57478434
SPECIFICATIONS
IN STOCK: 2
Can Ship immediately
Buy all 2 in-stock or the regular minimum order quantity of 5
On Order:
1,300
can ship 10/19/26
On Order:
1,300
can ship 3/29/27
Stock lot only: 2
Minimum Order Quantity: 5
Factory Lead-Time 40 Weeks
Price (USD)
3D PDF
Product Guides
Product Drawing - PLUG ASSEMBLY, SIZE 4, 37 POSITION, RIGHT ANGLE, FRONT METAL SHELL, .318 SERIES, BOARDLOCKS, AMPLIMITE HD-20
Datasheet
Product Specification - AMPLIMITE HD-20 PCB Mounted Connector
Instruction Sheet - AMPLIMITE .050 Series Connectors (Round-to-Flat Cable)
