5748526-1 by te connectivity / amp brand
Image is representational - see mfr. specs

5748526-1

TE Connectivity / AMP Brand

KIT,PLUG,9P,HDP-20,SHLD HDWRE ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

5748526-1 is an HDP-20 basic shielding hardware kit designed for 9-position D-subminiature plug connectors. This kit features shell size 1 with dimensions of 0.700 inches (Dim. D) and 1.535 inches (Dim. E), and supports a recommended cable outer diameter range of 0.165 to 0.455 inches with a maximum inner cable bundle diameter of 0.350 inches. The connector shell is made of steel with tin plating, and the insert is constructed from 94V-0 rated thermoplastic in black. It utilizes standard clinch nut mounting and accepts size 20 DF pin contacts. This shielding hardware kit is ideal for industrial machinery, medical instrumentation, computers and peripherals, and other applications requiring reliable D-subminiature connections with EMI shielding.

Product Highlights:

  • Connector Kit
  • Product Series = HDP-20 (Crimp Snap)
  • Number of Positions = 9
  • Shielded
  • Plug

Search Keywords: 57485261

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5748526-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538908180
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Bag
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Cable Mount
Gender:
Pin
Termination Method:
Crimp
Shell Size:
1
Number of Contacts:
9
Contact Plating:
N/A
Operating Temperature:
-55 to 105 °C

IN STOCK: 406

Can Ship immediately

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 350

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
5
$6.006
100
$5.072
250
$4.929
350
$4.860
700
$4.835
1,050
$4.811
1,400 +
$4.786
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
