5-794681-4

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

5-794681-4

RoHS:

Yes

HTS:

8536694040

COO:

CN

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

91

Package Type:

Tray

Sealable:

No

Mating Retention Type:

Locking Tab

Multiple Contact Types:

Without

Termination Method to Printed Circuit Board:

Through Hole - Solder

Contact Retention Within Housing:

Without

Connector & Contact Terminates To:

Printed Circuit Board

UL Flammability Rating:

UL 94V-0

Number of Signal Positions:

0

Contact Current Rating (Max):

5 A

Number of Positions:

24

Mating Retention:

With

Connector Mounting Type:

Board Mount

Housing Material:

Nylon

PCB Mount Alignment:

Without

Connector System:

Wire-to-Board

Mating Alignment:

With

PCB Contact Termination Area Plating Material:

Tin

Rectangular Power Connector Type:

Header

PCB Mount Orientation:

Vertical

Circuit Application:

Power

Panel Mount Feature:

Without

Contact Type:

Connector & Housing Type:

Plug

PCB Mount Retention:

With

Packaging Quantity:

91

Number of Power Positions:

24

Mating Alignment Type:

Polarization

Number of Rows:

2

Contact Mating Area Plating Material:

Tin

Housing Color:

Black

UL Rating:

Recognized

Header Type:

Fully Shrouded

Contact Mating Area Plating Material Thickness:

15 µin, .38 µm

Operating Temperature Range:

-40 – 105 °C, -40 – 221 °F

Centerline (Pitch):

.118 in, 3 mm

Wire Size:

30 – 20 AWG, 100.5 – 1022 CMA, .051 – .517 mm²

PCB Mount Retention Type:

Boardlock , Retention Bump

Termination Post & Tail Length:

.125 in, 3.18 mm

Row-to-Row Spacing:

.118 in, 3 mm

PCB Thickness (Recommended):

.062 in, 1.57 mm

Operating Voltage:

250 VAC, 250 VDC

Packaging Method:

Box & Tray , Tray

CSA Rating:

Certified , LR 7189

Agency/Standard:

CNR , USR

Glow Wire Rating:

GWT 750°C (Without Flame)

Approved Standards:

UL E28476

Glow Wire Material Rating:

Material with GWFI 850°C , Material with GWIT ≥ 775°C
