5-963860-1

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

5-963860-1

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

CZ

ECCN:

EAR99

Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.

This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.

4000

Package Type:

Reel

Terminal Type:

Tab

Primary Locking Feature:

Locking Lance

Interface Plating:

Tin (Sn)

Terminal Transmits:

25 – 40 A (Power)

Packaging Quantity:

4000

Termination Method to Wire & Cable:

Crimp

Sealable:

No

Packaging Method:

Reel

Mating Tab Thickness:

.031 in, .8 mm

Wire Size Search:

20 AWG, 21 AWG, 22 AWG, 23 AWG, 24 AWG, .2 mm², .25 mm², .3 mm², .4 mm², .5 mm²

Mating Tab Width:

.11 in, 2.8 mm

Tab Length:

1 in, 25.5 mm

Operating Temperature Range:

-40 – 130 °C, -40 – 266 °F

Wire Size:

24 – 20 AWG, .2 – .5 mm²

Crimp Type:

F-Crimp

Typical Current Rating:

30 A

Contact Size:

2.8mm

Operating Temperature (Max):

130 °C, 266 °F

Contact Fabrication:

Stamped & Formed

Wire Contact Termination Area Plating Material:

Tin
