5-968971-1

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

5-968971-1

RoHS:

Yes

HTS:

8538906000

COO:

HU

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

1800

Package Type:

Box

Packaging Quantity:

1800

Circuit Application:

Signal

Number of Positions:

9

Primary Locking Feature:

On the Terminal

Number of Rows:

3

Connector Position Assurance Capable:

No

Sealable:

No

Terminal Position Assurance:

Yes

Connector & Housing Type:

Housing for female terminals

Packaging Method:

Box

Operating Voltage:

28 VDC

Serviceable:

No

Connector System:

Wire-to-Wire

Cable Exit Angle:

180°

Product Width:

.827 in, 21 mm

Mating Tab Width:

.11 in, 2.8 mm

Centerline (Pitch):

.197 in, 5 mm

Nominal Voltage Architecture:

12 V, 24 V

Operating Temperature (Max):

100 °C, 105 °C, 110 °C, 120 °C, 70 °C, 75 °C, 80 °C, 85 °C, 90 °C, 158 °F

Operating Temperature Range:

-40 – 120 °C, -40 – 248 °F

Product Length:

.827 in, 21 mm

Housing Material:

PBT GF

Contact Size:

2.8mm

Mating Alignment:

With

Strain Relief:

Without

Contact Type:

Receptacle

Connector Height:

.945 in, 24 mm

Connector Mounting Type:

Cable Mount (Free-Hanging)

Connector Shape:

Rectangular

Mating Alignment Type:

Keyed
