601966-4 by te connectivity / amp brand
Image is representational - see mfr. specs

601966-4

TE Connectivity / AMP Brand

K-41 POSITIONER ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

601966-4 is a crimp tooling component used in wire termination processes to form electrical connections between wires and terminal barrels. The tooling is designed to achieve precise crimp height (CH) and crimp width (CW) dimensions that maintain an Area Index (AI) of approximately 80%, which is critical for ensuring proper electrical and mechanical connection quality. Key dimensional parameters include a nominal crimp height of 0.073 inches and crimp width of 0.110 inches, with a crimper leg taper of 3.0 degrees and anvil width of 0.109 inches. The tooling requires strict dimensional control to minimize clearance variations and prevent defects such as flash formation during the crimping process. This component is essential in production environments where consistent crimp quality, pull test values, and lead throughput are monitored to ensure reliable termination of electrical connectors.

Search Keywords: 6019664

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
601966-4
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8205595560
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack

IN STOCK: 3

Can Ship immediately

Factory Lead-Time 11 Weeks

Price (USD)

Qty
Unit Price
1
$164.80
5
$160.22
10
$158.02
20
$157.63
50
$151.79
100 +
$147.90
Log in for special pricing Click for Quote Price Match Request
