Image is representational - see mfr. specs

60894-1

TE Connectivity / AMP Brand

RECEPT,PIDG FASTON 22-18 110 ...

Datasheet

RoHS Compliant

Box Packaging

Certificate of Compliance Guarantee

DESCRIPTION

60894-1 is a FASTON receptacle terminal (.110/2.80) designed for electrical connections in industrial applications. It accommodates 22-18 AWG wire sizes (0.26-0.96 mm²) with a .032 inch (0.81 mm) crimp tab thickness. The terminal features a width of .146 inch (3.71 mm), length of .774 inch (18.64 mm), and a contact opening of .110 inch (2.79 mm). Constructed from high-conductivity copper with tin plating for corrosion protection, it includes a copper sleeve for vibration resistance and inner serrations for maximum electrical contact. The terminal is UL/CSA listed and MIL-Spec approved, with an operating temperature rating of 105°C and operating voltage of 300V, making it suitable for instruments, control systems, lighting, power supplies, and transportation applications.

Product Highlights:

Proprietary Name = PIDG FASTON
Receptacle Style = Straight
Wire Range = 0.30-0.90² [22-18] mm [AWG]
Tab Fit = 2.79 x 0.81 mm
Insulation Diameter = 2.54 [.100] Max. mm [in]

Potential Applications:

Search Keywords: 608941

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

60894-1

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
