6-103167-0 by te connectivity / amp brand
Image is representational - see mfr. specs

6-103167-0

TE Connectivity / AMP Brand

26 MODII HDR DRRA SHRD LF ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

6-103167-0 is a standard profile shrouded double-row header connector designed for the AMPMODU 0.100 inch [2.54 mm] centerline interconnection system. This connector features a shrouded design with 0.150 inch [3.81 mm] end dimension and supports position counts ranging from 8 to 72 positions in double-row configuration. The connector dimensions vary with position count, with dimension A ranging from 0.680 inches [17.27 mm] for 8 positions to 3.880 inches [98.55 mm] for 72 positions, and dimension B ranging from 0.600 inches [15.24 mm] to 3.800 inches [96.52 mm]. Available in multiple plating options (Plating A, B, and C) to meet various environmental and performance requirements, this connector is RoHS compliant and suitable for applications requiring reliable interconnection in compact, high-density PCB layouts.

Product Highlights:

  • Header
  • Header Type = Shrouded
  • Number of Rows = Dual
  • Number of Positions = 26
  • Mating Post Length = 8.08 mm

Search Keywords: 61031670

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
6-103167-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
112
Package Type:
Tray
Type:
Shrouded Header
Body Orientation:
Right Angle
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
26
Maximum Voltage Rating:
N/A
Maximum Current Rating:
3/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 125 °C

IN STOCK: 398

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 22 Weeks

Price (USD)

Qty
Unit Price
5
$8.31
25
$7.89
50
$7.71
112
$7.60
336
$7.40
560
$7.30
1,008 +
$5.57
Suppliers Standard Package
