6-1394461-3 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

6-1394461-3

PHOTOVOLT CONN PIN NEUTRAL 2.5 sq mm ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued
Certificate of Compliance

DESCRIPTION

The 6-1394461-3 is a neutral male connector designed for the SOLARLOK interconnection system used in photovoltaic applications. This connector is specifically engineered for 2.5 mm² / 14 AWG wire sizes with an insulation outer diameter range of 4.5 to 6.0 mm (0.177–0.236 in). Unlike polarity-keyed variants, the neutral male connector incorporates no keying features and may be freely mated to either "+" or "-" keyed female connectors, making it suitable for serial connections where polarity maintenance is not critical. The system operates at a maximum voltage of 1000 V (600 V for UL applications) with a maximum current rating of 25 A at 85°C, and functions reliably across an ambient temperature range of -40°C to +85°C. This connector is ideal for interconnecting firmly fixed cables in solar panel arrays, roof tile installations, and panel-to-inverter connections in photovoltaic systems.

Search Keywords: 613944613

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
6-1394461-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536698000
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Type:
Male Cable Coupler
Polarity:
N/A
IP Rating:
IP67
Termination Method:
Screw
Maximum Voltage Rating:
N/A
Maximum Current Rating:
25 A
Wire Size:
14 AWG
Operating Temperature:
N/A
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 1,440

Ships today, if you order in

Minimum Order Quantity: 30

Price (USD)

Qty
Unit Price
30
$2.64
100
$2.45
500
$2.13
1,000
$1.88
5,000
$1.77
10,000
$1.72
25,000 +
$1.70
Log in for special pricing

Tools/3D Models

Product Guides
