640506-3

TE Connectivity / AMP Brand

36P MR HDR ASSY V0 ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

640506-3 is a PC board vertical pin header designed for 36-circuit matrix miniature rectangular connectors with a 0.120 inch board thickness. This header features duplex finish plating with 0.000030 inch minimum gold in the mating area over 0.000050 inch minimum nickel underplate on the entire contact, combined with matte tin on the solder tail end. The header has a dimension A of 1.610 inches (40.89 mm) and dimension B of 0.180 inches (4.57 mm), providing precise spacing for high-density connector applications. It mates with socket housing part number 1-640526-0 and is RoHS compliant, making it suitable for industrial and commercial electronic assemblies requiring reliable multi-circuit interconnections.

Product Highlights:

  • Header
  • Number of Circuits = 36
  • 4.19 x 4.19 mm Centerline, Matrix
  • Matrix Contact Layout
  • Mount = PCB Thru Mount

Search Keywords: 6405063

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
640506-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
Bag
Type:
Rectangular
Mounting:
Through Hole
Body Orientation:
Straight
Gender:
RCP
Pitch:
4.19 mm
Termination Method:
Solder
Number of Contacts:
36
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
9/Contact A
Operating Temperature:
-55 to 105 °C

IN STOCK: 32

Can Ship immediately

Manufacturer Stock: 400   can ship 5/25/26

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 100

Factory Lead-Time 36 Weeks can ship 1/19/27

Price (USD)

Qty
Unit Price
5
$36.73
25
$36.64
50
$36.55
100
$36.46
200
$19.30
300
$13.59
400 +
$13.31
Suppliers Standard Package
