6469025-1 by te connectivity / amp brand

6469025-1

TE Connectivity / AMP Brand

Connector - Z-PACK Series - 40 Contacts - 2.5 mm - Header - Press Fit - 4 Rows. ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

When you have numerous wires connected in parallel, then use this high speed 6469025-1 backplane connector from TE Connectivity to make sure all the data flows through. This HDR connector's 40signal / 20ground contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. Its pitch is 2.5 mm. It has a straight body orientation. It has a maximum voltage rating of 250 VAC. This is a 4-row connector. This device has a maximum current rating of 7 A/contact. In order to ensure parts aren't damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. It uses the press fit termination method. This backplane connector has an operating temperature of -65 to 105 °C. This product is 24.95 mm long, 13.4 mm tall and 15.43 mm deep. 6469025-1 is housed in polyester.

Product Highlights:

  • Header
  • Connector Type = 10 Column
  • Interface Type = HM-Zd
  • Contact Type = ACTION PIN Post
  • Feedthrough Post Length = 2.50 mm

Search Keywords: 64690251

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
6469025-1
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
Tube
Type:
High Speed
Gender:
HDR
Body Orientation:
Straight
Mounting:
Through Hole
Pitch:
2.5 mm
Number of Contacts:
40Signal/20Ground
Termination Method:
PRESS FIT
Operating Temperature:
-65 to 105 °C

IN STOCK: 30,606

Can Ship immediately

Minimum Order: 20

Multiple: 20

Factory Lead-Time 2 Weeks

Price (USD)

Qty
Unit Price
1
$8.180
20
$7.437
40
$7.066
60
$6.932
100
$6.695
260
$6.561
500
$6.468
1,000 +
$6.396
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Accessories

1469028-1

HM-ZD 2PR RECP 40P

6469028-1

Connector, Z-PACK Series, 40 Contacts, 2 mm, Receptacle, Press Fit, 4 Rows
