6-66505-9 by te connectivity / amp brand
Image is representational - see mfr. specs

6-66505-9

TE Connectivity / AMP Brand

20 DF SOCKET CONT,SMALL PACK ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 6-66505-9 is a crimp snap-in contact with insulation support designed for use with AMPLIMITE subminiature D-type connectors in the HDP-20 contact size series. This socket contact is specified for wire sizes 24-20 AWG (0.2-0.6 mm) and features contact finish code A (cold flash over nickel on mating end, with additional tin-lead on termination end and entire contact nickel underplated). The contact is manufactured from phosphor bronze material and is compatible with the PRO-CRIMPER II hand tool (part number 66504-3) for loose form contact crimping applications. This contact is commonly used in precision-formed connector assemblies for electronic equipment requiring reliable miniature connections in space-constrained applications.

Search Keywords: 6665059

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
6-66505-9
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Box
Contact Type:
Signal
Gender:
SKT
Contact Size:
20
Wire Size:
24-28 AWG
Contact Material:
Phosphor Bronze
Contact Plating:
Gold Over Nickel,Gold Over Palladium Nickel
Maximum Current Rating:
N/A
Termination Method:
Crimp

IN STOCK: 2,289

Ships today, if you order in

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 4 Weeks

Price (USD)

Qty
Unit Price
100
$0.3351
500
$0.2997
1,000
$0.2990
2,500
$0.2508
5,000
$0.2277
7,500
$0.2247
10,000
$0.2107
15,000 +
$0.2080
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

91503-1

Hand Crimper Tool D-Sub Contacts

58448-2

PRO CR. ASSY AMPLIMITE IS 9357

58448-3

PRO-CRIMPER DIE

1579007-9

Extraction Tool for AMPLIMITE HD-20

91285-1

Insertion Tool, Insertion/Extraction Tool, Amplimite HDP-20, HDP-22 Series Contacts

Show 3 More
