DESCRIPTION

696369-1 is a PIDG FASTON tab terminal designed for use with 16-14 AWG stranded wire in receptacle applications. The terminal features a tin-plated brass body with a maximum insulation diameter of 0.197 inches (5.00 mm) and is designed to fit 0.250 inch receptacles with 0.032 inch thickness. The tab dimensions are 0.250 inches (6.35 mm) width and 0.866 inches (22.00 mm) length, with an end dimension of 0.300 inches (7.62 mm). This terminal is engineered for reliable crimped connections using TE's precision-matched tool and terminal concept, ensuring uniform insulation thickness and consistent crimp performance. The resulting termination is free of contamination, resistant to shock and critical environments, and provides tensile strength approaching that of the wire itself, making it suitable for demanding electrical applications requiring secure and durable connections.
