7-1904137-6

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

7-1904137-6

RoHS:

Yes

HTS:

8536490080

COO:

PT

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

18

Package Type:

Box

Coil Suppress:

Internal Coil Switch

Rated Coil Voltage:

12 VDC

Contact Limiting Breaking Current:

700 A

Contact Current Class:

201 – 500 A

Environmental Category of Protection:

RTI

Insulation Initial Dielectric Between Open Contacts:

4000 Vrms

Mounting Brackets:

Without

Contact Limiting Making Current:

250 A

Coil Resistance:

2.6 – 26 Ω

Rated Voltage:

800 VDC

Contact Arrangement:

1 form x (NO, DM)

Height Class (Mechanical):

40 – 50 mm

Contact Switching Voltage (Max):

900 VDC

Coil Power Rating Economized (Min):

620 mW

Mounting Type:

Screw

Insulation Initial Dielectric Between Coil & Contact Class:

4001 – 6000 V

Insulation Initial Dielectric Between Contacts & Coil:

4000 Vrms

Contact Base Material:

Silver Alloy

Coil Magnetic System:

Monostable, DC

Relay Type:

EVC 250 Main Contactor

Environmental Ambient Temperature Class:

-40 – 85 °C

Product Length:

3.37 in, 85.5 mm

Environmental Ambient Temperature (Max):

85 °C, 185 °F

Product Weight:

560 g, 19.7 oz

Product Width:

3.795 in, 96.4 mm

Product Height:

1.96 in, 49.8 mm
