747238-4 by te connectivity / amp brand
Image is representational - see mfr. specs

747238-4

TE Connectivity / AMP Brand

25 MSFL PLUG RA 318 (IN,FM) ...

Datasheet
RoHS Non-Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

747238-4 is a subminiature D-type right-angle posted plug connector designed for PCB mounting applications. This shell size 3 connector features 25 contact positions with size 20 DF posted pin contacts preloaded, and includes threaded inserts for secure mating. Key dimensions include A: 2.088 in (53.04 mm), B: 1.852 in (47.04 mm), D: 0.230 in (5.84 mm), and E: 0.738 in (18.75 mm), with a post diameter of 0.026 in (0.66 mm). The connector features a tin-plated steel front shell, 94V-0 rated black thermoplastic housing, and gold-plated mating end contacts (Plating Code A). It is ideal for applications requiring reliable signal connections in industrial, computing, and communication equipment.

Product Highlights:

  • Number of Positions = 25
  • Plug
  • PCB Mount Angle = Right Angle
  • Product Series = HD 20
  • With Mating Connector Lock

Search Keywords: 7472384

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
747238-4
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
65
Package Type:
Tray
Type:
D-Subminiature
Body Orientation:
Right Angle
Mounting:
Through Hole
Gender:
Pin
Termination Method:
Solder
Shell Size:
3
Number of Contacts:
25
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C
  This product is NOT RoHS Compliant.  See Alternatives

IN STOCK: 896

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
5
$6.99
25
$6.25
65
$6.12
130
$6.03
260
$5.86
520
$5.79
1,040
$4.64
2,535 +
$4.01
Suppliers Standard Package
