747532-8 by te connectivity / amp brand
Image is representational - see mfr. specs

747532-8

TE Connectivity / AMP Brand

KIT,RCPT,15P,HDE,SHLD HDWRE ...

Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

747532-8 is an AMPLIMITE D-subminiature cable connector receptacle designed for shielded cable applications. This shell size 2 receptacle features 15 contact positions with a tin-plated steel shell and 94V-0 rated thermoplastic insert. The connector has dimensions of 1.520 inches (Dim. C) and 1.002 inches (Dim. D), with a recommended cable outer diameter range of .165-.455 inches and maximum inner cable bundle diameter of .350 inches. The contact finish is gold flash on mating end with tin on termination end (Plating Code B), with entire contact nickel underplated. This RoHS compliant connector is suitable for industrial machinery, medical instrumentation, computers and peripherals, and data storage applications.

Product Highlights:

  • Connector Kit
  • Product Series = HDE-20 (IDC)
  • Number of Positions = 15
  • Shielded
  • Receptacle

Search Keywords: 7475328

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
747532-8
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536698000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Shell Plating Material:
Tin
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 824

Ships today, if you order in

Minimum Order Quantity: 5

Price (USD)

Qty
Unit Price
5
$7.56
25
$7.18
50
$7.01
100
$6.91
250
$6.73
500
$6.63
1,000 +
$6.53
