749111-8 by te connectivity / amp brand
Image is representational - see mfr. specs

749111-8

TE Connectivity / AMP Brand

100 50SR CABLE PLUG ASSY ...

Datasheet
RoHS Non-Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 749111-8 is a shielded D-subminiature cable connector plug designed for SCSI applications with 100 positions and .050 series spacing. It features insulation displacement crimp (IDC) termination for round jacketed cable with wire insulation diameters of 0.74–0.91 mm (0.029–0.036 in) and supports wire gauges of 30–28 AWG. The connector is constructed with a steel plug shell plated in tin-nickel alloy, phosphor bronze contacts with gold plating on the mating area, and includes a standard assembled termination cover. This connector is ideal for high-density signal transmission in industrial and computing applications requiring reliable shielded connections.

Product Highlights:

  • Connector
  • Plug
  • Number of Positions = 100
  • Wire/Cable Type = Round Jacketed Cable
  • Wire Range = 0.05-0.09² [30-28] mm [AWG]

Search Keywords: 7491118

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
749111-8
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
7
Package Type:
Tube
Type:
SCSI
Body Orientation:
Right Angle
Mounting:
Cable Mount
Gender:
PL
Termination Method:
IDT
Pitch:
1.27 mm
Number of Contacts:
100
Maximum Voltage Rating:
100 VDC
Maximum Current Rating:
1 A
Operating Temperature:
-55 to 105 °C
  This product is NOT RoHS Compliant.  See Alternatives

IN STOCK: 126

Ships today, if you order in

Minimum Order Quantity: 7

Multiple: 7

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
7
$9.00
28
$8.55
56
$8.35
105
$8.23
252
$8.01
504
$6.92
1,001 +
$5.51
