770057-1 by te connectivity / amp brand
Image is representational - see mfr. specs

770057-1

TE Connectivity / AMP Brand

15P UMNL II CAP-FRONT 94VO ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

770057-1 is a cap front housing component designed for use in the Universal MATE-N-LOK II 15-circuit matrix connector system. This component is part of a kit system (770030-1) that includes both front and rear cap housing components, with 770057-1 serving as the front piece and 770058-1 as the rear piece. The connector features a 0.250 inch (6.35 mm) centerline spacing and is designed for standard density applications. The housing is UL94V-0 rated for flammability and is RoHS compliant. These connectors are commonly used in wire-to-board applications for power circuits in home appliances and industrial equipment where reliable electrical connections are required.

Product Highlights:

  • Connector
  • Universal MATE-N-LOK II Product Line
  • Housing
  • Housing Gender = Receptacle
  • Not Preloaded

Search Keywords: 7700571

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
770057-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Mounting:
Panel Mount
Body Orientation:
Straight
Gender:
RCP
Termination Method:
N/A
Number of Contacts:
15
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
19/Contact A
Operating Temperature:
N/A

IN STOCK: 538

Can Ship immediately

On Order: 800   can ship 7/29/26

Minimum Order Quantity: 25

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
25
$1.804
250
$1.118
500
$1.014
1,000
$0.925
2,500
$0.851
5,000
$0.845
7,500
$0.843
10,000 +
$0.840
