770987-1 by te connectivity / amp brand
Image is representational - see mfr. specs

770987-1

TE Connectivity / AMP Brand

MINI UMNL PIN 22-18AWG SN LP ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

770987-1 is a brass pre-tinned crimp pin contact designed for use in AMP soft shell pin and socket connectors. It is rated for wire sizes 22-18 AWG (3-0.8 mm²) with insulation diameter range of 0.050-0.083 inches (1.27-2.11 mm). The contact features brass material with pre-tin plating for reliable electrical connection and corrosion resistance. It is supplied in loose piece form and is compatible with HDM applicator part number 567067-12 and hand tool part number 91522-1. This contact is commonly used in commercial connector applications requiring durable, high-density interconnections for industrial and electronic equipment.

Product Highlights:

  • Contact
  • Mini-Universal MATE-N-LOK
  • Pin
  • Loose Piece
  • Wire Range = 0.30-0.90² [22-18] mm [AWG], (2) 0.30-0.40² [(2) 22] mm [AWG]

Search Keywords: 7709871

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
770987-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Bag
Contact Type:
Power
Gender:
Pin
Contact Size:
N/A
Wire Size:
18-22 AWG
Contact Material:
Brass
Contact Plating:
Pre-Tin Over Nickel
Maximum Current Rating:
9.5 A
Termination Method:
Crimp
  Different packaging options available.  See Alternatives

IN STOCK: 20,889

Can Ship immediately

Minimum Order Quantity: 1000

Multiple: 1000

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
1
$0.1492
1,000
$0.1357
3,000
$0.1308
5,000
$0.1285
8,000
$0.1265
25,000
$0.1157
50,000
$0.0989
100,000
$0.0881
150,000 +
$0.0867
Suppliers Standard Package
