776539-1 by te connectivity / amp brand

776539-1

TE Connectivity / AMP Brand

Connector Housing - Red - AMPSEAL Series - Receptacle - 12 Positions - 4.5 mm - AMPSEAL 16 Connectors. ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 776539-1 is AMPSEAL 16 pin cap housing with integral primary latch reinforcement. These AMPSEAL 16 pin cap housings housings have colour coding and physical keying to prevent mismating. Pin cap housings consist of a cap housing with wire seal, wire seal cover and PLR. These AMPSEAL 16 pin cap housings have a reduced diameter wire seal and accept a wire size range of 1.30 to 2.54 mm.

Product Highlights:

  • Housing
  • Housing Type = Receptacle
  • 4.50 mm Centerline
  • In-Line Contact Layout
  • Number of Rows = 2

Search Keywords: 7765391

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
776539-1
RoHS:
Yes
HTS:
8538906000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Bag
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
RCP
Number of Contacts:
12
Maximum Voltage Rating:
N/A
Maximum Current Rating:
N/A
Operating Temperature:
N/A

IN STOCK: 1,425

Ships today, if you order in

Minimum Order: 10

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
10
$3.100
50
$2.225
250
$2.142
500
$2.112
1,000
$2.101
2,500
$2.091
5,000
$2.081
7,500 +
$2.070
Log in for special pricing
Click for Quote
