796689-2 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

796689-2

PCB Terminal Block - Header - Wire-to-Board - 2 Position - .197in (5 mm) Centerline - 35° Wire Entry - 30 to 12AWG - Screw, Rising Cage Clamp - Black. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 796689-2 is PCB terminal block with dimensions: 10.5 mm L x 12.5 mm D x 15 mm H. Operating temperature range is from -40 to 110 °C ( -40 to 230 °F ).

Product Highlights:

  • Connector
  • Connector Type = Wire Receptacle
  • Housing Color = Black
  • Not Side Stackable
  • Without Screw Flange

Search Keywords: 7966892

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
796689-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
IT
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
300
Package Type:
BOX
Type:
Eurostyle Block
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
5 mm
Number of Circuits:
2
Maximum Voltage Rating:
300 VAC
Maximum Current Rating:
17.5/Contact A
Wire Size:
12-30 AWG
Operating Temperature:
-40 to 105 °C

IN STOCK: 7,500

Ships today, if you order in

Minimum Order Quantity: 300

Multiple: 300

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
300
$0.6508
600
$0.6383
1,200
$0.6170
2,700
$0.6154
5,100
$0.5537
7,500
$0.5276
10,200
$0.5129
15,000 +
$0.4984
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides
