8-34854-1

Name: 8-34854-1
Brand: Te Connectivity Amp Brand
SKU: 10507775
Price: 63.57 USD
Availability: InStock

TERMINAL,PG R 12-10 10 ...

View Datasheet

Ask the Datasheet

RoHS Compliant

BOX Packaging

Certificate of Compliance

DESCRIPTION

8-34854-1 is a pre-insulated solderless hook tongue terminal designed for reliable wire termination in control circuits and power wiring applications. The terminal features a yellow vinyl insulation (UL 94V-0) with a copper body and tin plating per ASTM B-545, providing high dielectric strength and corrosion resistance. Dimensions include a width (W) of 0.375 inches (9.53 mm), a center-to-stud distance (C) of 7.67 mm, an overall length (L) of 22.68 mm, and a maximum insulation diameter of 6.35 mm. The terminal accommodates 12-10 AWG wire sizes (5.180-13.100 circular mils or 2.62-6.64 mm²) with a tongue material thickness of 0.042 inches and an M4 stud size. This terminal is ideal for high-speed production environments where funnel entry design enables easy wire insertion and serration features ensure exceptional barrel contact and tensile strength.

Product Highlights:

Terminal Shape = Ring Tongue
Receptacle Style = Straight
Body Style = PLASTI-GRIP
Barrel Type = Closed Barrel
Wire/Cable Type = Regular Wire

Potential Applications:

Search Keywords: 8348541

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

8-34854-1

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
