DESCRIPTION

9-146257-0 is a double row vertical breakaway header with solder tails, part of the AMPMODU .025 [0.64] square interconnection system. This header features 80 positions with .100 [2.54] centerline spacing and dimensions of A = 3.984 [101.19] inches/mm and B = 3.900 [99.06] inches/mm. The header has C = .120 [3.05], D = .230 [5.84], and E = .185 [4.70] dimensions with 30 Au Duplex plating option. It can be broken to desired number of positions using Tool Kit No. 314816-1. This RoHS compliant header is suitable for board-to-board interconnection applications requiring reliable vertical mounting configurations.

Product Highlights:

  • Header
  • Header Type = Breakaway
  • Number of Rows = Dual
  • Number of Positions = 80
  • Mating Post Length = 5.84 mm

Search Keywords: 91462570

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
9-146257-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
Carton
Type:
Unshrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
80
Maximum Voltage Rating:
N/A
Maximum Current Rating:
3/Contact A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C

IN STOCK: 5,894

Can Ship immediately

MOQ for In Stock Qty: 50

MOQ for out of Stock Qty: 50

Multiple: 50

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
50
$29.08
250
$29.00
500
$28.94
750
$28.87
1,500
$14.74
2,250
$10.03
3,000 +
$9.84
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
