926474-1 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

926474-1

Conn Housing RCP 2 POS 7.4mm Crimp ST Cable Mount Loose Piece ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

926474-1 is a FAST-IN-FASTON connector housing manufactured by AMP Incorporated, designed to accommodate 6.35 mm cavity terminals in a compact form factor. The housing features dimensions of 31.0 ±3 mm in length, 12.7 ±0.2 mm in width, and 12.4 ±0.3 mm in height, with a cavity depth of 9.4 ±0.3 mm and opening of 9.6 ±0.3 mm. The connector is constructed from PA 6 or PA 6.6 unfilled polyamide material, available in multiple colors including natural, black, orange, yellow, blue, green, red, violet, and gray. The product is air-tight packaged and complies with IEC 60335-1 standards, making it suitable for electrical appliance connections and industrial applications requiring reliable terminal retention and environmental protection.

Search Keywords: 9264741

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
926474-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
DE
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1000
Package Type:
BAG
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
RCP
Number of Contacts:
2
Maximum Voltage Rating:
250,250 VDC|VAC
Maximum Current Rating:
N/A
Operating Temperature:
N/A

IN STOCK: 2,670

Ships today, if you order in

Minimum Order Quantity: 25

Factory Lead-Time 11 Weeks

Price (USD)

Qty
Unit Price
25
$1.115
250
$0.720
500
$0.713
1,000
$0.693
3,000
$0.689
5,000
$0.657
8,000
$0.624
10,000 +
$0.610
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides
