967598-1 by te connectivity / amp brand

967598-1

TE Connectivity / AMP Brand

32pos MQS .63 header 180deg ...

Datasheet
RoHS Compliant
Carton Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / AMP Brand part 967598-1 is a high-quality 32-position MQS .63 header designed for reliable and efficient connectivity solutions. This versatile component features a 180-degree orientation, making it ideal for applications requiring straightforward, streamlined connections. It is engineered to deliver exceptional performance and durability, ensuring consistent electrical connectivity in a variety of demanding environments. The compact design of the 967598-1 allows for easy integration into electronic equipment, making it a suitable choice for automotive, industrial, and communication applications. Trust TE Connectivity for your critical connectivity needs and experience the superior reliability of the AMP Brand.

Product Highlights:

  • Pin Header
  • Number of Positions = 32
  • Without Tab Contacts
  • Without 2.5mm Pin Diameter Contacts
  • Without Fiber Optic Contacts

Search Keywords: 9675981

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
967598-1
RoHS:
Yes
HTS:
8536698000
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
220
Package Type:
Carton
Centerline (Pitch):
.1 in, 2.54 mm
Length:
1.99485 in, 51.15 mm
Mounting Holes:
Without
PCB Thickness (Recommended):
.031 – .063 in, .8 – 1.6 mm
Operating Temperature (Max):
65 °C, 70 °C, 75 °C, 80 °C, 85 °C, 149 °F, 158 °F, 167 °F, 176 °F, 185 °F
Number of Sections:
1
Sealable:
No
Packaging Quantity:
220
Voltage Rating (Max):
12 VDC
Termination Method:
Through Hole - Solder
Locking Interface:
Without
Width:
.608 in, 15.6 mm
Circuit Application:
Power & Signal
Connector & Contact Terminates To:
Printed Circuit Board
Nominal Voltage Architecture:
12 V
Tab Thickness:
.025 in, .63 mm
Interface Plating:
Tin (Sn)
PCB Mount Alignment:
With
UL Flammability Rating:
UL 94-HB
Profile Height from PCB:
.795 in, 20.2 mm
Hybrid Header:
No
Panel Mount Feature:
Without
Number of Positions:
32
Mounting Orientation:
Vertical/180 °
Color:
Gray
Operating Temperature Range:
-40 – 85 °C, -40 – 185 °F
PCB Mount Retention:
Without
Packaging Type:
Tray
Number of Signal Positions:
32
Tab Width:
.025 in, .63 mm
Number of Rows:
2
Shielded:
No
Operating Voltage:
12 VDC

IN STOCK: 430

Can Ship immediately

Minimum Order: 10

Factory Lead-Time 18 Weeks

Price (CAD)

Qty
Unit Price
10
$3.675
220
$2.416
440
$2.240
660
$2.227
1,100
$2.181
2,640
$2.061
5,060
$2.052
7,700 +
$2.041
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
