JMGACD-26MW

Electromechanical Relay 26.5VDC 1.56KOhm 1A DPDT (9.525x9.525x7.62)mm THT Military Relay ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The TE Connectivity/CII JMGACD-26MW is a high-quality electromechanical relay designed for military applications. With a voltage rating of 26.5VDC, this relay ensures reliable and efficient performance in demanding environments. It features a DPDT configuration, allowing for versatile control of multiple circuits. The relay has a low resistance of 1.56KOhm, ensuring minimal signal loss and maintaining high signal integrity. Measuring at just 9.525x9.525x7.62mm, this compact through-hole relay saves valuable space on PCBs. The JMGACD-26MW is a reliable and durable solution for military and other high-performance applications.

Product Highlights:

  • MGAD .100 Grid Relay Series
  • Input Voltage = 26.5 VDC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 1 Amps.
  • Non Polarized, Monostable Coil Magnetic System

Search Keywords: JMGACD26MW

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / CII Brand
Part No:
JMGACD-26MW
Alias/AKA:
M39016/18-042M, 1-1617146-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490050
COO:
IN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
BAG
Type:
Military Relay
Relay Construction:
Non-Latching
Contact Arrangement:
DPDT
AC Coil Voltage:
N/A
DC Coil Voltage:
26.5 V
Maximum Current Rating:
1 A
Coil Current:
16.99 mA
Coil Resistance:
1.56 KOhm
Mounting:
Through Hole
Operating Temperature:
-65 to 125 °C
Termination Style:
PC Pin

IN STOCK: 526

Can Ship immediately

MOQ for out of Stock Qty: 13

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
1
$198.65
5
$198.14
10
$197.65
13
$197.15
25
$108.55
38
$75.39
50 +
$73.87
Log in for special pricing
