JMGACD-5MW by te connectivity / cii brand

JMGACD-5MW

TE Connectivity / CII Brand

Electromechanical Relay 5VDC 50Ohm 1A DPDT (10.4x9.525x7.62)mm THT Military Relay ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE CONNECTIVITY / AMP BRAND part 1-1617146-8, also known as JMGACD-5MW = M39016/18-037M, is a high-quality, durable relay component designed to meet rigorous military specifications. Engineered for reliability and performance, this relay is ideal for applications requiring precise control and robust operation in demanding environments. Its military-grade construction ensures long-lasting functionality and resilience, making it a trusted choice for defense, aerospace, and other critical industries. The part's compact design facilitates easy integration into various systems, providing excellent performance without compromising on space or efficiency. Choose the JMGACD-5MW for a reliable solution that combines TE Connectivity's commitment to quality with the AMP brand's expertise in electrical components.

Product Highlights:

  • MGAD .100 Grid Relay Series
  • Input Voltage = 5 VDC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 1 Amps.
  • Non Polarized, Monostable Coil Magnetic System

Search Keywords: JMGACD5MW

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / CII Brand
Part No:
JMGACD-5MW
RoHS:
Yes
HTS:
8536410050
COO:
IN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Type:
Military Relay
Relay Construction:
Non-Latching
Contact Arrangement:
DPDT
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Maximum Current Rating:
1 A
Coil Current:
100 mA
Coil Resistance:
50 Ohm
Mounting:
Through Hole
Operating Temperature:
-65 to 125 °C
Termination Style:
Long Leads

IN STOCK: 34

Ships today, if you order in

On Order: 40   can ship 12/17/25

MOQ for out of Stock Qty: 13

Factory Lead-Time 18 Weeks

Price (CAD)

Qty
Unit Price
1
$233.830
5
$230.385
10
$149.715
13
$148.981
25
$140.236
38
$139.533
50 +
$134.463
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides
