23ESA103MMF50NF by te connectivity / citec brand
Image is representational - see manufacturer specifications
TE Connectivity / Citec Brand Authorized Distributor

23ESA103MMF50NF

Res Carbon Film POT 10K Ohm 20% 0.4W 1(Elec)/1(Mech)Turns 6.35mm (60.7 X 20.4 X 25.2mm) Eyelet Panel Mount ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 23ESA103MMF50NF is a Type 23 Series spindle-operated potentiometer manufactured by TE Connectivity, designed for versatile control applications requiring reliable resistance adjustment. This potentiometer features a 100 kO linear resistance element with ±20% tolerance, a 300° mechanical rotation range, and an insulated shaft extending 50 mm in length. It operates with a maximum operating torque of 15 mNm and end stop torque of 800 mNm, maintaining performance across an operating temperature range of -25°C to +70°C with mechanical endurance rated for a minimum of 15,000 operations. The device exhibits rugged construction with a printed carbon resistance element, die-cast metal bush, and is suitable for audio control, instrumentation, and industrial control panels where precise, durable potentiometer performance is required.

Product Highlights:

  • Potentiometer
  • 23 Series
  • Resistance Selection = K ?
  • Resistance = 10K ?
  • Power Rating = .40 W

Search Keywords: 23ESA103MMF50NF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Citec Brand
Part No:
23ESA103MMF50NF
Alias/AKA:
1623760-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533408070
COO:
GB
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
200
Package Type:
BOX
Mounting:
Panel Mount
Number of Turns:
1(Elec),1(Mech) Turns
Termination Style:
Eyelet
Power Rating:
0.4 W
Resistance Value:
10 KOhm
Tolerance:
20 %
Temperature Coefficient:
N/A
Dimension:
60.7 x 20.4 x 25.2 mm
Operating Temperature:
-25 to 70 °C

IN STOCK: 496

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 24 Weeks

Price (USD)

Qty
Unit Price
5
$3.76
50
$3.52
200
$3.38
400
$3.32
600
$3.27
1,000
$3.21
2,600 +
$3.12
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides
