DT06-08SA-EP07 by te connectivity / deutsch automotive
Image is representational - see manufacturer specifications
TE Connectivity / Deutsch Automotive Authorized Distributor

DT06-08SA-EP07

PLG, 8P, BLK, N, SEAL RET, A ...

View Datasheet
RoHS Compliant
Pack Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The TE CONNECTIVITY / DEUTSCH AUTOMOTIVE DT06-08SA-EP07 is a highly reliable and durable 8-position plug connector designed for demanding automotive and industrial applications. Featuring a sleek black design, this connector provides a robust and secure connection, ensuring optimal performance and stability. It includes a seal retainer to enhance environmental protection against dust, moisture, and other contaminants, making it ideal for harsh environments. With its user-friendly assembly, the DT06-08SA-EP07 simplifies installation and maintenance processes, offering efficiency and peace of mind. Whether used in automotive systems or industrial machinery, this plug connector ensures long-lasting connectivity with exceptional reliability. Perfect for engineers and technicians seeking quality and durability, this component meets high standards for demanding conditions.

Search Keywords: DT0608SAEP07

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Deutsch Automotive
Part No:
DT06-08SA-EP07
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Agency/Standard:
SAE J2030
Connector System:
Wire-to-Wire
Packaging Quantity:
500
Strain Relief:
Add By Accessory
Connector Position Assurance Capable:
No
Connector & Housing Type:
Housing for female terminals
Sealable:
Yes
Serviceable:
Yes
Primary Product Color:
Black
Primary Locking Feature:
Integrated in Housing
Number of Rows:
2
UL Flammability Rating:
12mm Flame Test per Standard UL-94
Number of Positions:
8
Terminal Position Assurance:
Yes
Contact Current Rating (Max):
13 A
Blank Cavity Position:
0
Packaging Method:
Box
Cable Exit Angle:
180°
Operating Temperature (Max):
125 °C, 257 °F
Centerline (Pitch):
.359 in, 9.12 mm
Product Width:
.776 in, 19.71 mm
Product Length:
1.217 in, 30.91 mm
Mating Pin Diameter:
.063 in, 1.59 mm
Operating Temperature Range:
-55 – 125 °C, -67 – 257 °F
Degree of Protection:
IP68 , IP6K9K
Nominal Voltage Architecture:
12 V, 24 V, 48 V
Operating Voltage:
250 VAC, 250 VDC
Row-to-Row Spacing:
.175 in, 4.45 mm
Circuit Application:
Power & Signal
Connector & Contact Terminates To:
Wire & Cable
Contact Type:
Socket
Housing Material:
PA GF
Connector Height:
1.465 in, 37.21 mm
Connector Shape:
Rectangular
Connector Mounting Type:
Cable Mount (Free-Hanging)
Contact Size:
Size 16
Mating Alignment:
With
Mating Alignment Type:
Keyed

IN STOCK: 105

Ships today, if you order in

On Order: 500   can ship 12/16/26

Minimum Order Quantity: 10

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
10
$3.64
50
$3.05
250
$2.82
500
$2.70
1,000
$2.59
2,500
$2.52
5,000
$2.45
7,500 +
$2.42
