D369-P99-NS0

Products found: 0

Supplier:

TE Connectivity / Deutsch

Part No:

D369-P99-NS0

RoHS:

Yes

HTS:

8538906000

COO:

GB

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

1

Package Type:

Bag

Strain Relief:

Without

Contact Transmits (Typical):

Signal

Shielded:

No

Number of Columns:

3

Connector System:

Wire-to-Wire

Seal Color:

Natural

Centerline (Pitch):

.1 in, 2.54 mm

Shell Material:

Composite

Contact Retention:

With

Shell Size:

9

Termination Method to Wire & Cable:

Crimp

Accepts Wire Insulation Diameter Range:

.028 – .054 in, .71 – 1.37 mm

Number of Rows:

3

Keying:

N

Cable Exit Angle:

180 °

Sealable:

Yes

Mating Retention Type:

Button Latch

Connector Style:

Plug

Fluid Resistance:

EN2591-315

Housing Color:

Black

Seal Type:

Triple-Seal

For Use With:

Shell Size 9

Interfacial Seal:

With

Mating Alignment Type:

Keyed

Seal Material:

Fluorosilicone

Mating Alignment:

With

Connection Type:

Connector Assembly

Operating Temperature Range:

-55 – 175 °C, -67 – 347 °F

Row-to-Row Spacing:

.1 in, 2.54 mm

Operating Voltage:

1500 VAC, 1000 VDC

Number of Cavities:

9

Size 22D Contact Quantity:

9

Material:

Composite

Circuit Application:

Signal

Contact Type:

Socket

Fluid Type:

EN2591-317

Housing Material:

Composite

Product Type:

Connector

Panel Gasket:

No

Mating Retention:

With

Rear Grommet:

With

Number of Positions:

9
