CONBNC004 by te connectivity / linx technologies
Image is representational - see manufacturer specifications
TE Connectivity / Linx Technologies Authorized Distributor

CONBNC004

BNC Jack 50 Ohm Panel Mount ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The CONBNC004 is a BNC panel-mount bulkhead jack (female socket) connector designed for RF and coaxial signal transmission in audio, video, broadcasting, and test equipment applications. It features a gold-plated brass center contact, gold-plated solder cup receptacle, and isolated ground enclosure design with a bayonet-style (push-twist) mating interface for reliable, easy-to-use connections. The connector operates across a frequency range of 0 Hz to 2 GHz with an impedance of 50 O, insertion loss of 0.48 dB maximum at sub-1 GHz and 0.52 dB maximum at 1–2 GHz, and VSWR of 1.3 maximum across both bands. It is rated for operating temperatures from -20 °C to +105 °C, meets RoHS and REACH lead-free standards, and is tested to withstand corrosion, vibration, mechanical shock, and thermal shock per MIL-STD-202 methods. The CONBNC004 is ideal for surveillance systems, industrial equipment, and enterprise networking where compact size, superior RF performance, and robust environmental resistance are required.

Search Keywords: CONBNC004

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Linx Technologies
Part No:
CONBNC004
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
TW
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
500
Package Type:
BAG
Impedance:
50 Ω
Operating Frequency:
2 GHz

IN STOCK: 810

Can Ship immediately

Minimum Order Quantity: 10

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
10
$2.71
50
$2.34
250
$2.29
500
$2.28
1,000
$2.27
2,500
$2.26
5,000
$2.25
7,500 +
$2.24
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides
