KUP-14D55-24 by te connectivity / p-b brand

KUP-14D55-24

TE Connectivity / P&B Brand

Power Relay 24VDC 10A 3PDT(48.4x38.9x35.7)mm Bracket ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / P&B Brand part KUP-14D55-24 is a versatile power relay designed for reliable performance in various applications. This 24VDC relay offers a 10A switching capacity and features a 3PDT (3-pole double throw) configuration, allowing for flexible control of electrical circuits. With compact dimensions measuring approximately (48.4x38.9x35.7)mm, this relay can easily fit into different types of control panels and circuit boards. Additionally, it comes with a bracket for convenient installation. Engineered with precision and durability in mind, the KUP-14D55-24 power relay ensures long-term functionality and efficient power management.

Product Highlights:

  • KUP Series
  • Contact Arrangement = 3 Form C, 3PDT, 3 C/O
  • Contact Current Rating = 10 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode

Search Keywords: KUP14D5524

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
KUP-14D55-24
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Pack
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
3PDT
Maximum Current Rating:
10 A
Mounting:
Bracket Mount
Termination Style:
0.187Quick Connect/Solder
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-45 to 70 °C
Coil Resistance:
472 Ohm
  Possible Replacement options available.  See Alternatives

IN STOCK: 484

Ships today, if you order in

Factory Lead-Time 18 Weeks
