RTE24012F by te connectivity / p-b brand
Image is representational - see mfr. specs

RTE24012F

TE Connectivity / P&B Brand

Power Relay DPDT (2 Form C) - 12VDC - 8A - 29mm x 12.7mm x 15.7mm - Through Hole - Standard Version. ...

Datasheet
RoHS Compliant
Carton Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The RTE24012F is a PCB Power Relay with DPDT-CO silver nickel contacts, non latching coil, sealed, plug-in/solder through hole terminals and 360Ω coil resistance. This RT2-series relay features reinforced insulation and 5mm pinning, wash tight/standard version.

Product Highlights:

  • RT2 Series
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 8 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode

Search Keywords: RTE24012F

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
RTE24012F
Alias/AKA:
3-1393237-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
Carton
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
DPDT
Maximum Current Rating:
8 A
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 85 °C
Coil Resistance:
360 Ohm
  Possible Replacement options available.  See Alternatives

IN STOCK: 49,800

Ships today, if you order in

Minimum Order Quantity: 20

Multiple: 20

Factory Lead-Time 23 Weeks

Price (USD)

Qty
Unit Price
20
$3.25
40
$3.18
100
$3.08
260
$3.03
500
$3.01
1,000
$2.60
2,500
$2.59
5,000 +
$2.56
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
