T92S7D14-24 by te connectivity / p-b brand
Image is representational - see mfr. specs

T92S7D14-24

TE Connectivity / P&B Brand

The T92S7D14-24 is a high-power, general-purpose PCB relay with a 2 Form A (NO) contact arrangement, AgSnOInO contacts, and a 24 VDC coil. ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The T92S7D14-24 is a T92 series high-power, general-purpose relay designed for PCB mounting. It features a 2 Form A (normally open) contact arrangement with silver tin oxide indium oxide contacts and is controlled by a 24 VDC coil with a rated power of 1.7W. This relay is capable of switching loads up to 40A at 240VAC and offers a high dielectric strength of 4000Vrms between the coil and contacts. Housed in a wash-tight, tape-sealed case, it is ideal for use in harsh environments and common applications such as HVAC systems, residential and commercial appliances, and industrial controls.

Search Keywords: T92S7D1424

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
T92S7D14-24
Alias/AKA:
1-1423008-8
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490080
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
30
Package Type:
Pack
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPST-NO
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-55 to 85 °C

IN STOCK: 3,057

Can Ship immediately

MOQ for out of Stock Qty: 60

Factory Lead-Time 23 Weeks

Price (USD)

Qty
Unit Price
1
$36.09
10
$30.80
25
$29.75
60
$27.80
120
$26.84
180
$26.71
240 +
$26.31
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
