TXR18AB00-1610AI

Backshell - Ruggedized - 1.224" (31.10mm) Diameter - Shell Size 16, 16S - 7/8-20 UNEF Thread - 180° Cable Exit - Tinel Lock - Unshielded - Olive Drab. ...

Datasheet

RoHS Non-Compliant

Pack Packaging

DESCRIPTION

The TXR18AB00-1610AI from TE Connectivity / Raychem Brand is unshielded ruggedized backshell with 1.224" (31.10mm) outside diameter, shell size 16, 16S and 7/8-20 UNEF thread. This olive drab backshell has 180° cable exit and tinel lock. Cable entry diameter range is from .01 to .63 in (.2 to 15.9 mm). Operating temperature range is from -65 to 175 °C ( -85 to 347 °F ).

Product Highlights:

Terminate To Cable
Style = Tinel Lock
Connector Code = 18
Straight
Shell Size = 16, 16S

Potential Applications:

Search Keywords: TXR18AB001610AI

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / Raychem Brand

Part No:

TXR18AB00-1610AI

RoHS:

HTS:

8538908180

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

Package Type:

Pack

Shell Size:

Angular Function:

180 °

Coupling:

N/A

Body Material:

Aluminum Alloy

Body Plating:

Olive Drab Cadmium Over Electroless Nickel

Entry Size:

10 mm

Operating Temperature:

N/A

IN STOCK: 2

Ships today, if you order in

You may purchase all in-stock quantity of 2

BONDED Quantity: 0

Manufacturer Stock: 0

MOQ for In Stock Qty: 50

Available in less than min: 2

MOQ for out of Stock Qty: 50

Multiple: 1

Factory Lead-Time 68 Weeks

This product is no longer being manufactured but there may be alternatives. We can help you, Contact Us.

Price (CAD)

Qty

Unit Price

$1,337.505

$1,197.691

$1,179.714

$1,162.012

$617.236

$414.630

50 +

$406.331

Click for Quote
