TXR54AB00-2012BI by te connectivity / raychem brand
Image is representational - see manufacturer specifications
TE Connectivity / Raychem Brand Authorized Distributor

TXR54AB00-2012BI

Backshell - Heat Shrink Adapter - 1.343"(34.10mm) Outside Diameter - Shell Size 20, 37 - 1 3/16-18 UNEF Thread Size - 180° Cable Exit - Entry Size 12. ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The TXR54AB00-2012BI from TE Connectivity / Raychem Brand is shielded backshell, heat shrink adapter with shell size 20/37, entry size 12 and ring to suit double braid. This backshell has 1.343" (34.10mm) outside diameter, 1 3/16-18 UNEF thread size and 180° cable exit. The TXR54AB00-2012BI include: 1 backshell, 1 braid and 1 tinel ring. Operating temperature range is from -65 to 175 °C ( -85 to 347 °F ).

Product Highlights:

  • Terminate To Cable
  • Style = Tinel Lock
  • Connector Code = 54
  • Straight
  • Shell Size = 20, 37

Search Keywords: TXR54AB002012BI

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Raychem Brand
Part No:
TXR54AB00-2012BI
Alias/AKA:
266641-000
Unit of Measure:
Per Each
RoHS:
No
HTS:
8538908180
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
BAG
Shell Size:
20
Angular Function:
180 °
Coupling:
N/A
Body Material:
Aluminum Alloy
Body Plating:
Olive Drab Cadmium Over Electroless Nickel
Entry Size:
12 mm
Operating Temperature:
N/A

IN STOCK: 184

Ships today, if you order in

MOQ for out of Stock Qty: 13

Factory Lead-Time 25 Weeks

Price (USD)

Qty
Unit Price
1
$189.80
5
$173.62
10
$166.47
13
$164.82
25
$163.19
38
$161.58
50 +
$159.97
