TXR54AB00-2216AI by te connectivity / raychem brand

TXR54AB00-2216AI

TE Connectivity / Raychem Brand

Backshell - Heat Shrink Adapter - 1.468" (37.29mm) Outside Diameter - Shell Size 22 - 1 5/16-18 UNEF Thread Size - 180° Cable Exit - Entry Size 16. ...

Datasheet
RoHS Non-Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TXR54AB00-2216AI from TE Connectivity / Raychem Brand is shielded backshell, heat shrink adapter with shell size 22, entry size 16 and ring to suit single braid. This backshell has 1.468" (37.29mm) outside diameter, 1 5/16-18 UNEF thread size and 180° cable exit. The TXR54AB00-2216AI include: 1 backshell, 1 braid and 1 tinel ring. Operating temperature range is from -65 to 175 °C ( -85 to 347 °F ).

Search Keywords: TXR54AB002216AI

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Raychem Brand
Part No:
TXR54AB00-2216AI
RoHS:
No
HTS:
8538908180
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Shell Size:
22
Angular Function:
180 °
Coupling:
N/A
Body Material:
Aluminum Alloy
Body Plating:
Olive Drab Cadmium Over Electroless Nickel
Entry Size:
25.4 mm
Operating Temperature:
-65 to 175 °C

IN STOCK: 26

Can Ship immediately

On Order: 100   can ship 3/11/26

Factory Lead-Time 55 Weeks

Price (CAD)

Qty
Unit Price
1
$242.512
5
$224.413
10
$214.795
15
$205.975
25
$202.883
50 +
$199.835
