FN2070-3-06 by te connectivity / schaffner emc
Image is representational - see mfr. specs

FN2070-3-06

TE Connectivity / SCHAFFNER EMC

The FN2070-3-06 is a two-stage, chassis-mount EMI filter with a rated current of 3A, designed for high differential and common-mode attenuation. ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The FN2070-3-06 is a two-stage EMI filter designed to provide high conducted attenuation performance in noisy applications. It operates with a rated current of 3 A at 40°C, a maximum operating voltage of 250 VAC, and across a frequency range from DC to 400 Hz. Key electrical characteristics include an inductance of 9.8 mH, a Cx capacitance of 0.47 µF, a Cy capacitance of 4.7 nF, and a leakage current of 0.734 mA at 230 VAC. Designed for reliable performance, it has an operating temperature range of -25°C to +100°C. This filter is ideal for various applications such as industrial machinery, electronic data processing equipment, and consumer goods requiring effective EMI suppression.

Search Keywords: FN2070306

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / SCHAFFNER EMC
Part No:
FN2070-3-06
Alias/AKA:
800576-SF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
Box
Mounting:
Flange Mount
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
3 A
Operating Frequency:
0 to 400 Hz
Operating Temperature:
-25 to 100 °C
Dimension:
85 x 54 x 40.3 mm

IN STOCK: 70

Can Ship immediately

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
1
$35.52
5
$30.31
20
$25.80
40
$24.28
60
$23.42
100
$22.39
260 +
$21.84
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
