682-1Y by teledyne mil ssr
Image is representational - see mfr. specs

682-1Y

Teledyne Mil SSR

Relay - Optically Isolated - 1A @ 250Vrms - Hermetically Sealed DIP Pkg - Tested Per MIL-PRF-28570 - Marked "682-1Y" ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 682-1Y is no longer qualifed as an M28750/9-001 relay.

The 682-1Y is an optically isolated AC solid-state relay designed for power switching applications. It operates with a control input voltage from 3.8 to 32 Vdc and switches AC loads up to 250 Vrms over a frequency range of 40 to 440 Hz. Key features include a 1A output current rating (2A with a heatsink), zero-voltage turn-on for low EMI, and the ability to handle surge currents up to 8 Apk. Optical isolation provides a dielectric strength of 1500 Vac between the input and output. Tested using MIL-PRF-28750 Tesst Methods, and housed in a hermetically sealed metal DIP package, the 682-1Y is ideal for high-reliability military and aerospace applications requiring robust performance in harsh environments.

Search Keywords: 6821Y

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Teledyne Mil SSR
Part No:
682-1Y
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541409500
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
TRAY
Output Type:
AC
Maximum Output Voltage:
250(RMS) V
Maximum Output Current:
2(RMS) A
Output Device:
SCR
Input Type:
DC
Input Voltage:
32 V
Mounting:
Through Hole
Circuit Arrangement:
N/A
Dimension:
22.6(Max) x 13.5(Max) x 4.83(Max) mm

IN STOCK: 0

On Order: 103   can ship 12/21/26

MOQ for out of Stock Qty: 50

Factory Lead-Time 44 Weeks

Price (USD)

Qty
Unit Price
1
$1,016.24
10
$974.40
25
$964.75
50
$955.20
100
$952.81
150
$950.43
200 +
$948.05
