GRF303-5 by teledyne relays

GRF303-5

Teledyne Relays

Electromechanical Relay - 5VDC - 100Ohm - 1A - DPDT - (9.52x10.41x10.6)mm - SMD Signal Relay. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The GRF303-5 ultraminiature GRF303 relays are designed to provide a practical surface-mount solution with improved RF signal repeatability over the frequency range. GRF303 relays feature a unique ground shield that isolates and shields each lead to ensure excellent contact-tocontact and pole-to-pole isolation. The GRF303 version with the improved ground connections can push the performance up into the 10Gbps data rates for digital signal integrity applications. This ground shield provides a ground interface that results in improved high-frequency performance as well as parametric repeatability. The GRF300 extend performance advantages over similar RF devices that simply offer formed leads for surface mounting. These relays are engineered for use in RF attenuator, RF switch matrices, ATE and other applications that require dependable high frequency signal fidelity and performance.

Search Keywords: GRF3035

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Teledyne Relays
Part No:
GRF303-5
RoHS:
Yes
HTS:
8536410020
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Relay Construction:
Non-Latching
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT
Maximum Current Rating:
1 A
Mounting:
Surface Mount
Pin Count:
8
Operating Temperature:
-55 to 85 °C
Dimension:
9.52 x 10.41 x 10.6 mm
Termination Style:
N/A

IN STOCK: 1,067

Ships today, if you order in

On Order: 700   can ship 2/20/26

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$116.730
5
$114.907
10
$108.232
15
$107.697
25
$104.576
50 +
$96.295
